Kõrvaklapi võimendi Sugden MASTERCLASS HA 4

In 1967 Sugden released the world’s first solid state pure class A amplifier, the A21.

The HA-4 is not only a state of the art class A headphone amplifier, it can also be used as a compact high-end pre-amplifier. The design is similar to our top of the range Sapphire DAP-800 and will drive any dynamic headphone. Featuring Sugden VCV circuit and coupled to a pure class A zero feedback mosfet output stage. The HA-4 is unconditionally load stable with a discrete constant voltage series power supply. A high input impedance ensures absolute minimal loss of signal with perfect current gain.


Facilities

Inputs One line level input, one balanced input

Outputs Stereo ¼” jack socket, one line level output

Volume Control Manual operation


Specifications

Input Impedance 20k Ohms

Gain 16dB

Channel Separation >90dB

Frequency Response >0.3dB 20Hz-30kHz

Signal to Noise >95dB

Output Impedance 1 Ohm

Gross Weight (packed) 6kgs

Dimensions 80 x 250 x 310mm (hwd)


Värvid:
Standardvärvid titanium või grafiit
Erivärvid hinnalisaga + EUR 148
